| Product SKU | MFS1707C |
| Brand | KTS Turbobillet X |
| Availability | In Stock |
| Quantity |
|
Description
Highlight
KTS Turbobillet X (KTS) is a specialty manufacturer of high performance Machined-From-Solid (MFS) Compressor wheel, also known as Billet Impeller.
Any Inquiry feel free to contact us via:
Facebook: www.facebook.com/KtsTurbobilletX
Email: sales2@ktsturbobilletx.com
|
KTS MFS P/N |
1707 |
|
OE MODEL |
GT15-25 |
|
OE COMPRESSOR WHEEL P/N |
706164-0003 |
|
OE TURBOCHARGER P/N |
UNK |
|
APPLIED TO ENGINE/VEHICLE |
Renault |
|
FITS COMPRESSOR HOUSING |
OE |
|
NOSE DIAMETER (mm) |
11.77 |
|
INDUCER (mm) |
34.65 |
|
EXDUCER (mm) |
49.00 |
|
TIP EXDUCER (mm) |
- |
|
TIP HEIGHT (mm) |
4.40 |
|
SUPERBACK (mm) |
2.40 |
|
BORE SIZE (mm) |
5.08 |
|
BORE TYPE |
Through |
|
OVERALL HEIGHT (mm) |
24.89 |
|
BLADE NUMBER |
6+6 |
|
ROTATION |
Forward |
What's in the box
KTS Billet Compressor Wheel MFS1707C x 1pc
